Nylon Lock Hex Nut
Nylon locking hexagon txiv ntseej tsuas yog tso siab rau cov nylon ntxhua khaub ncaws hauv cov txiv ntoo hexagon los ua lub luag haujlwm xauv, uas feem ntau hu ua nylon txiv ntoo lossis nylon ntxig cov txiv ntoo los yog tsuas yog xauv cov txiv ntoo hauv kev lag luam. Nylon hex txiv ntseej yog siv los ua ke nrog threaded screws lossis bolts rau kev sib txuas.
- Kev xa khoom sai
- Quality Assurance
- 24/7 Kev Pabcuam Cov Neeg Siv Khoom
Khoom Taw qhia
Nylon locking hexagon txiv ntseej tsuas yog tso siab rau cov nylon ntxhua khaub ncaws hauv cov txiv ntoo hexagon los ua lub luag haujlwm xauv, uas feem ntau hu ua nylon txiv ntoo lossis nylon ntxig cov txiv ntoo los yog tsuas yog xauv cov txiv ntoo hauv kev lag luam. Nylon hex txiv ntseej yog siv los ua ke nrog threaded screws lossis bolts rau kev sib txuas. Tom qab kaw, lub nplhaib nylon yuav deform thiab sau qhov sib txawv ntawm cov khoom sib txuas ntawm ob qho kawg, yog li ua lub luag haujlwm xauv.
Nylon locking hexagon txiv ntseej yog ua los ntawm carbon steel los yog stainless hlau. Muaj garde 4 nylon xauv txiv ntoo, qib 8 nylon xauv txiv ntoo feem ntau nrog cov hlau. Tsis tas li ntawd muaj stainless hlau nylon ntxig hex txiv ntoo, xws li 304 lossis 316 khoom. Jinrui tuaj yeem ua ob yam khoom. Lub teb chaws tus qauv yog DIN985 thiab DIN982. Lub nplhaib nylon tuaj yeem yog xim xiav lossis xim dawb.Cov txheej tuaj yeem ua zinc plated nylon txiv ntoo, tab sis tsis tuaj yeem ua HDG, vim HDG tuaj yeem ua rau lub nplhaib nylon puas.
Ib sab ntawm cov nylon xauv txiv ntoo yog hexagonal thiab lwm sab yog puag ncig, thiab lub nplhaib nylon ntxiv rau sab puag ncig, txhawm rau txwv cov txiv ntoo kom tsuas yog nruj rau qee txoj haujlwm.
Cov txheej txheem ntau lawm ntawm Nylon Lock Hex Txiv Ntoo
Specification ntawm Nylon Lock Hex Nut
d | M3 | M4 | M5 | M6 | M7 | M8 | M10 | M12 | M14 | M16 | M18 | |
e | min | 6.01 | 7.66 | 8.79 | 11.05 | 12.12 | 14.38 | 18.9 | 21.1 | 24.49 | 26.75 | 29.56 |
h | max | 4 | 5 | 5 | 6 | 7.5 | 8 | 10 | 12 | 14 | 16 | 18.5 |
min | 3.7 | 4.7 | 4.7 | 5.7 | 7.14 | 7.64 | 9.64 | 11.57 | 13.3 | 15.3 | 17.66 | |
m | min | 2.4 | 2.9 | 3.2 | 4 | 4.7 | 5.5 | 6.5 | 8 | 9.5 | 10.5 | 13 |
s | max | 5.5 | 7 | 8 | 10 | 11 | 13 | 17 | 19 | 22 | 24 | 27 |
min | 5.32 | 6.78 | 7.78 | 9.78 | 10.73 | 12.73 | 16.73 | 18.67 | 21.67 | 23.67 | 26.16 | |
d | M20 | M22 | M24 | M27 | M30 | M33 | M36 | M39 | M42 | M45 | M48 | |
e | min | 32.95 | 35.03 | 39.55 | 45.2 | 50.85 | 55.37 | 60.79 | 66.44 | 72.09 | 76.95 | 82.6 |
h | max | 20 | 22 | 24 | 27 | 30 | 33 | 36 | 39 | 42 | 45 | 48 |
min | 18.7 | 20.7 | 22.7 | 25.7 | 28.7 | 31.4 | 34.4 | 37.4 | 40.4 | 43.4 | 46.4 | |
m | min | 14 | 15 | 15 | 17 | 19 | 22 | 25 | 27 | 29 | 32 | 36 |
s | max | 30 | 32 | 36 | 41 | 46 | 50 | 55 | 60 | 65 | 70 | 75 |
min | 29.16 | 31 | 35 | 40 | 45 | 49 | 53.8 | 58.8 | 63.8 | 68.1 | 73.1 | |
Common Qib thiab Txheej
Txuj | Khoom siv | Qib | Ua kom tiav | Xov |
DIN933 | carbon hlau | 4.6 | Plain | UNC |
Zinc plated | ||||
Hlau alloy | Yellow zinc plated | |||
PTFE | ||||
Stainless hlau | Dub Oxide | UNF | ||
Dacromet | ||||
Lwm yam | HDG | |||
Lwm yam |
Daim Ntawv Thov Cheeb Tsam ntawm Nylon Lock Hex Nut
Lub nylon xauv hex txiv ntseej tsim los ntawm Jinrui muaj ntau yam kev siv. Xws li petrochemical, tsheb tsim, kev tsim kho, cov kav dej siab, kev tsheb ciav hlau, steel qauv engineering, loj fais fab tsim tshuab thiab infrastructure. Tau kawg, hauv qee qhov chaw tshwj xeeb hauv cov teb no, lwm yam khoom siv kuj tseem siv, xws li cov ntsia hlau ntsia hlau, flange ceev, U-bolts, lub taub hau tiaj tus hex bolts, T-bolts, hex bolts thiab puag ncig lub taub hau hex bolts.
FAQ
Q1: Koj puas yog lub Hoobkas lossis tuam txhab lag luam?
A: Peb yog cov chaw tsim khoom ntawm hex bolts thiab txiv ntoo rau ntau tshaj 20 xyoo. Peb muaj ob lub Hoobkas, ib qho hauv Shanghai thiab lwm qhov hauv Jiangsu. Peb lub peev xwm ntau lawm tuaj yeem yog 20000 ntxiv rau tons hauv ib xyoos. Peb tuaj yeem kho peb cov khoom raws li cov neeg siv khoom xav tau, kos duab thiab qauv.
Q2: Muaj pes tsawg xyoo koj ua lag luam txawv teb chaws?
A: Peb muaj ntau tshaj 20 xyoo dhau los hauv kev xa khoom mus rau thoob ntiaj teb nrog peb cov khoom zoo tshaj plaws. Tam sim no peb tau xa tawm ntau tshaj 40 lub teb chaws, xws li Spain, Lub Tebchaws Yelemees, Ltalis, Belgium, United Kingdom, Lithuania, Tebchaws USA, Canada, Australia, Singapore, Nyiv, Thaib, Malaysia, Kaus Lim Qab Teb, Indonesia, Egypt, Philippines thiab lwm yam.
Q3: Koj puas muaj cov khoom tso tawm txaus?
A: Peb muaj Tshuag txaus hauv warehouses nrog ntau peev. Peb muab kev pabcuam 24- teev. Rau feem ntau cov qauv, peb muaj lawv ntawm Tshuag, xws li hex bolts, hex txiv ntseej, thiab lwm yam.
Q4: Yuav ua li cas kom ntseeg tau tias txhua tus txheej txheem zoo?
A: Ua ntej, peb muaj kev kos duab rau txhua yam khoom thaum tsim khoom.
Qhov thib ob, peb cov neeg ua haujlwm feem ntau muaj ntau tshaj 10- xyoo dhau los ntawm kev ua hex bolts.
Thib peb, peb cov neeg QC yuav kuaj xyuas txhua 2 teev. Yog tias pom qhov tsis zoo, lawv yuav nres qhov porduction tam sim ntawd.
Tom qab ntawd, cov khoom tiav yuav raug kuaj xyuas dua ua ntej xa khoom xa tuaj uas lav txhua yam khoom zoo.
Q5: Yuav ua li cas kom muaj kev nyab xeeb ntawm kev thauj mus los ntev?
A: Peb ntim rau hauv cov thawv ua ntej, thiab tom qab ntawd ntim cov thawv rau ntawm pallets. Lub pallet yog yooj yim heev los nqa los ntawm Forklift wihch yuav tiv thaiv cov thawv los ntawm kev puas tsuaj. Cov pab pawg kws tshaj lij uas khaws txhua qhov kev ntim khoom kom zoo.
Q6: Yam khoom twg koj tuaj yeem hloov kho?
A: Ib qho yog cov qauv, xws li DIN933, hex bolts. Lwm qhov yog Non-standard qhov chaw. Yog tias koj xav tau cov qauv, koj tuaj yeem qhia tus qauv, qhov loj me, qib (khoom siv), txheej thiab kom muaj nuj nqis. Piv txwv li, koj xav yuav DIN933, M12X60, qib 8.8, zinc plated thiab 20000pcs.
Yog tias koj xav tau qhov tsis yog tus qauv, koj tuaj yeem qhia peb cov qauv, kos duab lossis cov lus piav qhia ntxaws. Tom qab ntawd peb tus engineer yuav ua cov duab kos rau koj.
Muaj ntau ntau, xws li hexagon bolts, flange bolts, puag ncig lub taub hau square caj dab bolts, raws li zoo raws li khiav bolts, U-bolts, T-bolts, tiaj tus taub hau hexagon bolts, hex ceev, hex flange ceev.
Q7: Koj puas tuaj yeem muab qee yam qauv?
A: Cov qauv tuaj yeem muab tau raws li koj xav tau.
Cim npe nrov: nylon xauv hex txiv ntseej, Tuam Tshoj, tuam ntxhab, lwm tus muag khoom, Hoobkas, kev cai, lag luam wholesale, nqe
